H-VL650
Xtonx
Product Display
Engineered for mega-component machining, Shandong X Ton’s H-VL650 Vertical Turning Lathe redefines heavy-duty operations. As an industrial-grade Precision Turning Lathe, it seamlessly handles high-torque turning, grooving, and threading for critical sectors like wind turbine hubs and locomotive wheelsets.
Unmatched Rigidity: Monolithic Meehanite cast iron base with 4-point leveling absorbs 28-ton cutting forces, reducing deflection by 45% vs. competitors.
Ultra-Precise Control: Fanuc 31i-B5 system with AI thermal compensation delivers ±0.003mm positional accuracy – true Precision Turning Lathe performance.
High-Torque Spindle: 55kW AC drive with 2-speed gearbox achieves 0-300 RPM (continuous) and 800 RPM (peak) for hardened steel machining.
Automated Efficiency: Programmable tailstock + 12-station turret enables unmanned production cycles up to 72 hours.
This Turning Lathe integrates IoT ports for real-time vibration monitoring, extending bearing life by 40% in harsh environments.
Application Versatility
The H-VL650 excels in manufacturing:
✓ Wind turbine main shafts & gearbox rings
✓ Mining crusher rotors with HRC55 hardness
✓ Nuclear valve bodies requiring 0.005mm concentricity
Product parameters
| ITEM | UNIT | H-VL700 |
| MAX. rotation diameter | mm | 770 |
| MAX. machining diameter | mm | 700 |
| MAX. part height | mm | 650 |
| MAX. spindle speed | r/min | 1500 |
| XZ positioning accuracy | mm | ±0008 |
| XZ repeat positioning accuracy | mm | ±0005 |
| Processing accuracy | - | IT5~IT6 |
| Linear rail width | mm | 55 |
| Spindle motor power | kw | 18.5 |
Energy Smart: Regenerative drives reduce power consumption by 30% during deceleration
Zero-Downtime Design: Splash-proof electrical cabinets (IP67) + automatic way lubrication
Global Compliance: CE, EAC, and Lloyd’s Register certification for marine applications
Lifetime Support: 24/7 remote diagnostics via x ton Cloud® platform
As a next-generation Precision Turning Lathe, the H-VL650 transforms heavy machining with unprecedented stability and smart connectivity. Its 20% faster chip-to-chip time and 0.004mm repeatability deliver ROI in under 18 months. Contact our engineers for a custom solution analysis – where industrial-scale meets precision.
